Rotary Welding Systems

Automated Positioning for Precise Circular Welding

We offer advanced Rotary Welding Systems for precise, efficient welding of circular and cylindrical components. Designed for smooth rotation, accurate positioning, and MIG, TIG, and SAW compatibility, they improve weld consistency and productivity in industrial applications.

360° Rotation Control: Enables smooth and accurate positioning of the workpiece
Tilt Functionality: Provides flexibility to achieve perfect welding angles (Manual/Motorized)
Variable Speed Adjustment: Ensures precision and adaptability for different welding diameters
High Load Capacity: Designed to handle heavy work pieces with stability
Motor and Drive: Industry standard and reputed quality AC motor and three phase VFD drive unit
TIG Compatible: Isolated faceplate with pressure earth clamp, TIG HF compatible unit

Enquiry now Whatsapp Now

Technical Specifications

Model	Load Capacity at 0° (kg)	Load Capacity at 90° (kg)	Face plate Diameter (mm)	Rotation Speed (RPM)	Drive Method	Tilting Method	Tilting Angle	Tilting Speed (secs)	Center of Gravity (mm)
WTT-50	50	25	325	0.1-2.5/0.1-8.0	AC motor with reduction gear and VFD	Manual	0°-90°	NA	100
WTT-150	150	75	475	0.1-1.5/0.1-2.5		Manual	0°-90°	NA	100
WTT-300	300	150	650	0.1-1.5		Manual/Motorized	0°-90°	NA/60	150
WTT-500	500	250	800	0.1-1.5		Motorized	0-135	60	150
WTT-1000	1000	500	1200	0.1-1.0		Motorized	0-135	90	150
WTT-2000	2000	1000	1500	0.1-1.0		Motorized	0-135	90	150
WATT-5000	5000	2500	1500	0.05-0.5/0.1-1.0		Motorized	0-135	120	150

Note: Continuous development entitle us to change/upgrade/modify specifications without any notice.
Kindly confirm specifications while placing order with us.
